PWM DC motor speed controller Digital display 0~100% adjustable drive module 6V~60V Input Max30A

SPECIFICATIONS

PWM DC motor speed controller Digital display  0~100% adjustable drive module 6V~60V Input Max30A

adjust speed range:: 0~100%

Voltage:: 6V~60V(6V 9V 12V 24V 36V 48V 60V)

Product Name:: Digital display PWM controller

Origin: CN(Origin)

Motor Type: DC Motor

Model:: PWM-30AD2

Model Number: MAX 30A digital display speed ratio DC motor Speed controller

The PWM controller must be loaded with equipment in order to work properly. Please do not test without load.

Digital display PWM DC motor speed controller display 0~100% adjustable drive module 6V12V24V36V48V60V Max30A current regulator for control motor speed.

• working voltage:6V~60V

• output voltage:Linear under load

• Maximum current:30A

• Continuous current:20A

• Speed control range:0%——100%digital display

• Overload protection: SEFUSE

• Speed control mode:Use potentiometer regulating current

• Modular size:75MM*56MM*28MM

•
