Digital PID Temperature Temp Controller RKC REX-C410 48*96mm Horizontal, Input thermocouple K,PT100,J Relay Output for heat

$24.05 USD
$28.06 USD $24.05 USD
Sale Sold out
Shipping calculated at checkout.
Color

SPECIFICATIONS

Digital PID Temperature Temp Controller RKC REX-C410 48*96mm Horizontal, Input thermocouple K,PT100,J Relay Output for heat

Usage: Industrial

Unit Type: piece

Theory: Temperature Controller

Style: Standing Station

Size: 48*96*900mm

Power Type: Charger

Package Weight: 0.4kg (0.88lb.)

Package Size: 12cm x 5cm x 10cm (4.72in x 1.97in x 3.94in)

Model Number: REX-C410

Max Measuring Temperature: 120°C & Above

Input: Thermocouple/RTD

Display Type: DIGITAL

Display Size: 2.0 - 3.9 Inches

Display: Celsius °C

Control output: Relay

Alarm output: ALM1

Features:
This is a bid for a dual display universal digital programmable temperature controller that supports many type of thermocouple sensor. It can be powered by 85-265V AC, Comsumption5VA.




  • Model: REX-C410
  • PID control

Specifications:

  • Display: Dual display for Celsius (°C)
  • Range: -0-400°C (Only when with the factory K type thermocouple)

Thermocouple: K,J,S,E,R,Wre3 ~ Wre25

Thermo Resistor: PT100, Cu50

  • Main Output: Relay:
  • PID cooling/heating control
  • 1 RELAY alarm: Normal open, capacity 250V/3A AC or 30V/3A DC
  • 7 different Dual Output combinations with: high / low / high deviation / low deviation /interval / out of interval / breakage alarm
  • Accuracy: 0.5%
  • Input: K
  • Dimension:  48mm x 96mm x 900mm
  • Weight: about 300g
  • Individually programmable PID control parameters.
    P, I, d, controlling period, digital filter coefficient, and more
  • Relay control ready to connect
  • Input: TC(K, J, S, E) / RTD (Pt100, CU50) universal input
  • Control output: RELAY
  • Alarm output: 1 line output, 7 kinds of alarm mode: high/low/high deviation/low deviation/interval/out of interval/breakage alarm.
Package include:
  • 1x REX-C410 PID Temperature Controller ( not included thermocouple)
  • 1x User Manual in English
