Switching Power Supply Transformer 12 24 V AC-DC Power Supply 110V 220V to 12V 24V 36V 48V 1A 20A 30A SMPS LED Strip Light CCTV

Regular price $28.00 NZD
Regular price $28.00 NZD Sale price $28.00 NZD
Sale Sold out
Shipping calculated at checkout.
Power

SPECIFICATIONS

Switching Power Supply Transformer 12 24 V AC-DC Power Supply 110V 220V to 12V 24V 36V 48V 1A 20A 30A SMPS LED Strip Light CCTV

Origin: Mainland China

Output Type: single

Output Current: 0-30A

Output Power: 401 - 500w

is_customized: Yes

Certification: RoHS

Features:
High price-effective, reliability with industry standards.
Built-in over voltage, over current, and short circuit protection.
PWM design, make sure the stability and high efficiency of power supply.
Anti-jamming, passed EMC test, wave less than 20MV.
Constant voltage output, assume stable power supply for Led lightings to reach long lifetime.
Specifications:
Type:Switching Power Supply
Main Material:Metal+Electronic Parts
Main Color:Silver (As pictures show)
Input Voltage:AC 110/220V±15%,50/60Hz
Output Voltage&Output Current&Output Power:
DC 24V 1A 24W
DC 24V 2A 48W
DC 24V 3A 72W
DC 24V 5A 120W
DC 24V 15A 360W
DC 24V 25A 600W
Working Temperature:0~60 degree Celsius
Storage Temperature:-20~60 degree Celsius
Ambient Humidity:0~95%RH Non-Condensation
Item Size:
1A 24W: 8.6cm*5.9cm*3.4cm / 3.39inch*2.32inch*1.34inch (L*W*H)
2A 48W:8.6cm*5.9cm*3.4cm / 3.39inch*2.32inch*1.34inch (L*W*H)
3A 72W:11.1cm*7.9cm*3.7cm / 4.37inch*3.11inch*1.46inch (L*W*H)
5A 120W:13cm*10cm*4.1cm / 5.12inch*3.94inch*1.61inch (L*W*H)
15A 360W:21.5cm*11.5cm*5.1cm / 8.47inch*4.53inch*2inch (L*W*H)
25A 600W:24.2cm*12.5cm*6.6cm / 9.53inch*4.92inch*2.6inch (L*W*H)
Net Weight/Item:
1A 24W: 0.087kg / 3.07oz
2A 48W:0.11kg / 3.88oz
3A 72W:0.202kg / 7.13oz
5A 120W:0.293kg / 10.34oz
15A 360W:0.729kg / 25.72oz
25A 600W:1.132kg / 39.93oz
Package Include:
1*Switching Power Supply
DC 24V 1A 24W:
DC 24V 2A 48W:
DC 24V 3A 72W:
DC 24V 5A 120W:
DC 24V 15A 360W:built-in fan on/off control circuit,fan automatically works according to working temperature.
DC 24V 25A 600W:
Notes:
1. High Voltage inside,do not remove the cover.Qualified service personnel only.
2. 110V/220V is selected by switch before power on,please check the input voltage avolding damage.
Connection:
L,N: AC power input
V-: DC power output -
V+: DC power output +
Vo/ADJ: Adjust the output voltage
