DC24V 360LPH 70M Lift Small Submersible Solar Water Pump for Solar System

Regular price $344.00 NZD
Regular price $283.00 NZD Sale price $344.00 NZD
Sale Sold out
Shipping calculated at checkout.
Default Title

SPECIFICATIONS

DC24V 360LPH 70M Lift Small Submersible Solar Water Pump for Solar System

Brand Name: BLUSUNSOLAR

Structure: Submersible Pump

Power: Electric

Fuel: Other

Origin: CHINA

Pressure: High Pressure

Usage: Water

Model Number: Water Pump

Application: Submersible

Theory: Vortex Pump

Standard or Nonstandard: Standard

Type: Solar Water Pump

Color: Orange / Blue/Black

A map Max: 8 A

Volt: 24V DC

Flow Rate: 360/96

Lift Max: 70 meters

Submersion Max: 30 meters

Packing size: 355*130*110

Weight: 3 kg





DC24V 360LPH 70M Lift Small Submersible Solar Water Pump For Solar System



This pump delivers a steady 96GPH(360LPH) at its maximum depth of 230 feet(70M) when supplied with 24VDC.

Its unique water-tight power connector stops water wicking and prevents potential condensation problems.Great

for livestock watering.Irrigation pondaeration.remote homes and cabins,

Features:
1. For 4" wells or larger
2. Quick disconnect with "Watertight-Gland" Design Pat Pend
3. Corrosion-proof housing with stainless-steel fastener
4. Run dry without damage
5. State of the art solid diaphragm
6. Stainless Steel Fastener
7. Pump Design: Positive Displacement 3 Chamber Diaphragm Pump
8. Motor: Permanent Magnet Thermally Protected
9. Internal Bypass: 105-110 PSI Max. (7.2-7.5 BARS)
10. Outlet Port: 1/2" (12.7mm) Barbed Fitting
11. Inlet: 50 Mesh Stainless Steel Screen
12. Material: High Strength Engineered Plastic
13. the solar panel must be more than 150W for this pump
24V

Solar water pump
1041749192_375HTB1JylvKpXXXXciXXXXq6xXFXXXGHigh-lift-dc-12v-solar-submersible-deep-well-pumpsHTB17_U8KXXXXXa0XVXXq6xXFXXXBHTB1nONoKpXXXXbkXpXXq6xXFXXXYHTB1POhvKpXXXXctXXXXq6xXFXXXB

1231612132_143

For more information please leave message to us, we will reply you soon, thank you!
