  • CHNT leakage breaker NXBLE-32 3p+n 80a 30mA RCD rcbo
1 8

CHINT ELECRTIC

CHNT NXBLE Residual Current Circuit Breaker RCCB 1P+N/2P/3P/3P+N/4P

$30.00 NZD
$30.00 NZD
Sale Sold out
Shipping calculated at checkout.
Poles Number
Rated Current

CHNT NXBLE Residual Current Circuit Breaker RCCB 1P+N/2P/3P/3P+N/4P C Type Earth Leakage Protection MCB 6A~125A Leakage Air Switch for Home Distribution Box

DESCRIPTION

Original CHNT NXBLE series leakage circuit breaker, C curve instantaneous trip(5In-10In), rated residual operating current 30mA, available 1P+N/2P(AC230V single phase),3P/3P+N/4P(AC400V three phase), current range 6A/10A/16A/20A/25A/32A/40A/50A/63A/80A/100A/125A, overload+short circuit+earth leakage triple protection, magnetic blow-out arc extinguishing, household PZ30 distribution cabinet installation, residential & industrial power distribution use.

  • Triple protection: overload, short-circuit and earth leakage protection, 30mA sensitive leakage trip for personal electric shock safety
  • C-type tripping characteristic, suitable for household resistive & inductive loads like lamp, socket, air conditioner
  • Standard DIN rail installation, match PZ30 domestic distribution cabinet, easy wiring & maintenance
  • Magnetic blowout arc extinguishing structure, stable arc cutting, long service life
  • Complete specification:1P+N/2P single phase 230V,3P/3P+N/4P three phase 400V, full current from 6A to125A

Specification

属性项目 参数详情
Brand CHNT (正泰)
Model NXBLE-32 / NXBLE-63 / NXBLE-125
Product Type Residual Current Operated Circuit Breaker(RCCB+MCB, Leakage Air Circuit Breaker)
Trip Curve C Type(C Curve, Instantaneous trip:5~10In)
Pole Option 1P+N、2P、3P、3P+N、4P
Rated Current(In) NXBLE-32:6/10/16/20/25/32A；NXBLE-63:40/50/63A；NXBLE-125:80/100/125A
Rated Voltage 1P+N/2P:AC230V；3P/3P+N/4P:AC400V
Residual Operating Current 30mA(Standard household leakage protection)
Arc Extinguish Mode Magnetic Blow-out Type
Mounting Standard DIN rail mount, PZ30 distribution box compatible
Protection Function Overload Protection + Short Circuit Protection + Earth Leakage Protection
Application Household indoor distribution, socket/lighting/air conditioner circuit, three-phase equipment power control
