CHNT JZX-22F(D) Miniature Electromagnetic Intermediate Relay 2Z/3Z/4Z

Description

• JZX-22F(D)/2Z(8Pin,2NO+2NC,5A)、3Z(11Pin,3NO+3NC,5A)、4Z(14Pin,4NO+4NC,3A);
• JQX-13F(D): Thick 8Pin specification.


  Available coil voltage: DC12V,DC24V,AC24V,AC220V,AC380V; silver alloy contact, fast operate & release time ≤20ms, pluggable design with optional matching DIN socket base for easy replacement. Widely used for PLC cabinet signal conversion, equipment interlock, water pump/fan/motor auxiliary circuit control, automation equipment switching control.

• Diversified Contact & Pin Options: 8/11/14 pin & 2Z/3Z/4Z multiple contact combinations plus JQX-13F thick 8pin model, fully meet different circuit interlock design demands.
• Rich Coil Voltage Range: DC12/24V & AC24/220/380V optional, compatible with most global common industrial & household control power supply.
• Premium Silver Alloy Contacts: Silver alloy contact ensures stable switching, anti-oxidation & long service life under frequent on-off cycles.
• Convenient Plug-in Design: Separate relay or relay+base kit available, pluggable structure enables quick disassembly & replacement without rewiring.
• Wide Application Scenarios: Perfect for automation equipment, PLC cabinet signal amplification, fan/water pump/motor auxiliary circuit control, building electrical interlock system.

Specification

Main Model & Parameter Table
