50 Pair/lot Special Design Solar Photovoltaic Junction Box Terminal Boxes for Solar PV System FS0146
Regular price
Dhs. 2,497.00 AED
Regular price
Dhs. 1,918.00 AED
Sale price
Dhs. 2,497.00 AED
Unit price
per
Shipping calculated at checkout.
Free Shipping Above 200 AED
شحن مجاني عند طلبك أكثر من 200 درهم إماراتي
شحن مجاني عند طلبك أكثر من 200 درهم إماراتي
Couldn't load pickup availability
SPECIFICATIONS
50 Pair/lot Special Design Solar Photovoltaic Junction Box Terminal Boxes for Solar PV System FS0146
Brand Name: BLUSUNSOLAR
Origin: Mainland China
Model Number: PV Combiner Boxes
Amount of Rails: 1 Rail Terminal
Rated Voltage: TUV 1000V DC
Rating Current: 3-20A(Potting)
Proof Voltage: TUV 6000V AC(1min) / UL 2200V DC (1min)
Contact Material: Copper, Tin Plated
BOX Material: PPO
Cable Size: 2.5mm sq (1M)
Protection Class: Class II
Pollution Degree: 2
Pin Od: 4.0mm
1 Way Solar Junction Box with 1M 2.5mm2 Cable and IP67 SOLAR Connector
Production introduction:
| Product No. | SM-JB1A |
| Amount of rails | 1 rail terminal |
| Rated Voltage | TUV 1000V DC |
| Rating current | 3-20A(Potting) |
| Suitable cable cross sections | 2.5mm2-6.0mm2 / 14AWG-10AWG |
| Pin OD | 4.0mm |
| Proof voltage | TUV 6000V AC(1Min) / UL 2200V DC (1Min) |
| Pollution degree | 2 |
| Protection class | Class II |
| Contact Material | Copper, tin plated |
| Contact resistance | ≤5mΩ |
| Protection degree | IP67 |
| Withdrawal Force | ≥50N |
| Temperature Range | -40ºC~+85ºC |
| Flame Class | UL94V-0 |
